WALL PANEL
LR, DNVGL, ABS, BV, KR, NK 등
선급의 규정에 적합한 테스트를 통해 검증되었으며
방화, 방음, 경량에 대한 기능이 우수하고 설치가 용이합니다.
Standard wall panel system[Spline joint]
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative materialDimension : Standard width : 600mm, Maximum length : 3600mm
| Type |  |
 |
||
|---|---|---|---|---|
| Model no. | W-102 | W-151 | W-102S | W-151S |
| Thickness | 50mm | 25mm | 50mm | 25mm |
| Fire class | B-15 | B-15 | B-15 | B-15 B-0 |
| Weight | 18.86kg/㎡ | 15.07kg/㎡ | 20.08kg/㎡ | 16.00kg/㎡ |
| Sound reduction |
Rw 31dB | Rw 31dB | Rw 31dB | Rw 30dB |
| Thermal transmittance |
0.58kcal/㎡h℃ | 1.06kcal/㎡h℃ | 0.58kcal/㎡h℃ | 1.06kcal/㎡h℃ |
Insert type wall panel system
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative materialDimension : Standard width : 580mm, Maximum length : 3600mm
| Type |  |
|
|---|---|---|
| Model no. | W-308 | W-358 |
| Thickness | 50mm | 25mm |
| Fire class | B-15 | B-0 |
| Weight | 18.22kg/㎡ | 14.34kg/㎡ |
| Sound reduction |
Rw 33dB | Rw 33dB |
| Thermal transmittance |
0.58kcal/㎡h℃ | 1.06kcal/㎡h℃ |
A-60 Class wall panel
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative materialDimension : Standard width : 600mm, Maximum length : 3600mm
| Type |  |
|
|---|---|---|
| Model no. | W-A60 | |
| Thickness | 100mm | |
| Fire class | A-60 | |
| Weight | 39.01kg/㎡ | |
| Sound reduction |
Rw 52dB | |
| Thermal transmittance |
0.30kcal/㎡h℃ | |
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative material
Dimension : Standard width : 550mm, Maximum length : 3600mm
| Type |  |
 |
|---|---|---|
| Model no. | W-A60R | W-100R |
| Thickness | 100mm | 100mm |
| Fire class | A-60 | A-60 |
| Weight | 35.3kg/㎡ | 27.3kg/㎡ |
| Sound reduction |
Rw 49dB | - |
| Thermal transmittance |
0.30kcal/㎡h℃ | 0.30kcal/㎡h℃ |
High noise reduction wall panel
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative materialDimension : Standard width : 600mm, Maximum length : 3600mm
| Type |  |
 |
 |
 |
|---|---|---|---|---|
| Model no. | W-102SN | W-106S | W-106SE(6) | W-151SD |
| Thickness | 50mm | 50mm | 50mm | 75mm |
| Fire class | B-15 | B-15 | B-15 | B-15 |
| Weight | 19.80kg/㎡ | 23.75kg/㎡ | 24.16kg/㎡ | 31.53kg/㎡ |
| Sound reduction |
Rw 37dB | Rw 41dB | Rw 46dB | Rw 53dB |
| Thermal transmittance |
0.58kcal/㎡h℃ | 0.58kcal/㎡h℃ | 0.58kcal/㎡h℃ | 0.55kcal/㎡h℃ |
Surface finish : 0.6mm thickness galvanized steel sheet finished with decorative material
Dimension : Standard width : 550mm, Maximum length : 3600mm
| Type |  |
 |
 |
|---|---|---|---|
| Model no. | W-302S | W-302E | W-302SE |
| Thickness | 50mm | 50mm | 50mm |
| Fire class | B-15 | B-15 | B-15 |
| Weight | 21.72kg/㎡ | 22.30kg/㎡ | 22.96kg/㎡ |
| Sound reduction |
Rw 42dB | Rw 44dB | Rw 46dB |
| Thermal transmittance |
0.58kcal/㎡h℃ | 0.58kcal/㎡h℃ | 0.58kcal/㎡h℃ |
Light weight wall panel
Surface finish : 0.4mm thickness galvanized high tensile steel sheet finished with decoratiove materialDimension : Standard width : 600mm, Maximum length : 3600mm
| Type |  |
|
|---|---|---|
| Model no. | W-202S | W-251S |
| Thickness | 50mm | 25mm |
| Fire class | B-15 | B-0 |
| Weight | 16.88kg/㎡ | 12.80kg/㎡ |
| Sound reduction |
Rw 31dB | Rw 31dB |
| Thermal transmittance |
0.58kcal/㎡h℃ | 1.06kcal/㎡h℃ |
Surface finish : 0.6mm thickness anodized aluminum sheet finished with decorative material
Dimension : Standard width : 600mm, Maximum length : 3600mm
| Type |  |
|
|---|---|---|
| Model no. | WA-402S | WA-451S |
| Thickness | 50mm | 25mm |
| Fire class | B-15 | B-0 |
| Weight | 13.78kg/㎡ | 9.70kg/㎡ |
| Sound reduction |
- | - |
| Thermal transmittance |
0.58kcal/㎡h℃ | 1.06kcal/㎡h℃ |
